GTFS-1000L Tuning Fork Level Switch

GTFS-1000L Tuning Fork Level Switch
Application：Solid Particles , Powder, Liquid
Medium Temperature：-20～200℃
Power：3W
Time Delay：1-30s
Vibrating frequency：300±50HZ
 Contactor Capacity：SPDT 8A/250V AC
Electrical Interface：M20*1.5
Working Pressure：≦2Mpa
Working Voltage：24V DC/220V AC
Protection Grade：IP65


        The working principle of tuning fork level switch is that the probe is based on the tuning fork design, adopts piezoelectric devices to realized the vibration driving and detection of the fork body. When not in contact with materials, the tuning fork will vibrate at the resonant frequency; once it is contacted by the materials, the vibration amplitude of the tuning fork decreases obviously, and the output signal amplitude of the piezoelectric detection device decreases accordingly. The signal change will be detected and analyzed by the intelligent circuit and a switching signal will be output.
